How to deploy MySQL 5.7 & 8.0 master-slave cluster using Docker

> Deploy MySQL 5.7 cluster master & slave (for testing only)

Image version 5.7

1. Create an overlay network

docker network create --driver overlay common-network --attachable

2. Edit two configuration files master.cnf and slave.cnf

!includedir /etc/mysql/conf.d/
!includedir /etc/mysql/mysql.conf.d/

[mysqld]
log-bin=mysql-bin
server-id=1
gtid-mode=ON
enforce-gtid-consistency=ON

!includedir /etc/mysql/conf.d/
!includedir /etc/mysql/mysql.conf.d/

[mysqld]
server-id=2
gtid-mode=ON
enforce-gtid-consistency=ON

3. Start 2 MYSQL: mysql-master, mysql-slave

docker run -d \
--name mysql-master \
--network common-network \
-e MYSQL_ROOT_PASSWORD=Passw0rd \
-v `pwd`/master.cnf:/etc/mysql/my.cnf \
-p 3306:3306 \
-d mysql:5.7

docker run -d \
--name mysql-slave \
--network common-network \
-e MYSQL_ROOT_PASSWORD=Passw0rd \
-v `pwd`/slave.cnf:/etc/mysql/my.cnf \
-p 3307:3306 \
-d mysql:5.7

4. Add users from the library for replication

docker run -it --rm --network common-network mysql mysql -hmysql-master -uroot -pPassw0rd \
-e "CREATE USER 'repl'@'%' IDENTIFIED BY 'password' REQUIRE SSL; " \
-e "GRANT REPLICATION SLAVE ON *.* TO 'repl'@'%';"

5. Connect master & slave

docker run -it --rm --network common-network mysql mysql -hmysql-slave -uroot -pPassw0rd \
-e "CHANGE MASTER TO MASTER_HOST='mysql-master', MASTER_PORT=3306, MASTER_USER='repl', MASTER_PASSWORD='password', MASTER_AUTO_POSITION=1, MASTER_SSL=1;" \
-e "START SLAVE;"

6. Verify slave status

docker run -it --rm --network common-network mysql mysql -hmysql-slave -uroot -pPassw0rd -e "show slave status\G"

The following status is normal:

Slave_IO_Running: Yes

Slave_SQL_Running: Yes

> Deploy MySQL 8.0 cluster master & slave (for testing only)

Mirror version mysql:8.0

1. Create an overlay network

docker network create --driver overlay common-network --attachable

2. Start 2 MYSQL: mysql-master, mysql-slave

docker run -d \
--name mysql-master \
--network common-network \
-e MYSQL_ROOT_PASSWORD=Passw0rd \
-p 3306:3306 \
-d mysql --default-authentication-plugin=mysql_native_password

docker run -d \
--name mysql-slave \
--network common-network \
-e MYSQL_ROOT_PASSWORD=Passw0rd \
-p 3307:3306 \
-d mysql --default-authentication-plugin=mysql_native_password

3. Configure master & slave

docker run -it --rm --network common-network mysql mysql -hmysql-master -uroot -pPassw0rd \
-e "SET PERSIST server_id=1;" \
-e "SET PERSIST_ONLY gtid_mode=ON;" \
-e "SET PERSIST_ONLY enforce_gtid_consistency=true; " \
-e "CREATE USER 'repl'@'%' IDENTIFIED BY 'password' REQUIRE SSL; " \
-e "GRANT REPLICATION SLAVE ON *.* TO 'repl'@'%';"

docker run -it --rm --network common-network mysql mysql -hmysql-slave -uroot -pPassw0rd \
-e "SET PERSIST server_id=2;" \
-e "SET PERSIST_ONLY gtid_mode=ON;" \
-e "SET PERSIST_ONLY enforce_gtid_consistency=true; "

4. Restart master & slave

docker restart mysql-master mysql-slave

5. Connect master & slave

docker run -it --rm --network common-network mysql mysql -hmysql-slave -uroot -pPassw0rd \
-e "CHANGE MASTER TO MASTER_HOST='mysql-master', MASTER_PORT=3306, MASTER_USER='repl', MASTER_PASSWORD='password', MASTER_AUTO_POSITION=1, MASTER_SSL=1;" \
-e "START SLAVE;"

6. Verify slave status

docker run -it --rm --network common-network mysql mysql -hmysql-slave -uroot -pPassw0rd -e "show slave status\G"

The following status is normal:

Slave_IO_Running: Yes

Slave_SQL_Running: Yes

> Verify data synchronization

Create database anoyi on master

docker run -it --rm --network common-network mysql mysql -hmysql-master -uroot -pPassw0rd \
 -e "create database anoyi default character set utf8mb4 collate utf8mb4_general_ci;"

View the database list on the slave

docker run -it --rm --network common-network mysql mysql -hmysql-slave -uroot -pPassw0rd \
 -e "show databases;"
mysql: [Warning] Using a password on the command line interface can be insecure.
+--------------------+
| Database |
+--------------------+
|anoyi |
| information_schema |
|mysql |
| performance_schema |
|sys|
+--------------------+

Related information:

MySQL 5.7: https://dev.mysql.com/doc/refman/5.7/en/replication.html
MySQL 8.0: https://dev.mysql.com/doc/refman/8.0/en/replication.html
