Pure CSS3 code to implement a running clock

Pure CSS3 code to implement a running clock

Operation effect

Code Implementation

html

<div id="watch">
  <div class="frame-face"></div>
  <ul class="minute-marks">
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
  </ul>
  <div class="digital-wrap">
    <ul class="digit-hours">
      <li>23</li>
      <li>00</li><li>01</li><li>02</li><li>03</li><li>04</li><li>05</li>
      <li>06</li><li>07</li><li>08</li><li>09</li><li>10</li><li>11</li>
      <li>12</li><li>13</li><li>14</li><li>15</li><li>16</li><li>17</li>
      <li>18</li><li>19</li><li>20</li><li>21</li><li>22</li>
    </ul>
    <ul class="digit-minutes">
      <li>10</li><li>11</li>
      <li>12</li><li>13</li><li>14</li><li>15</li><li>16</li><li>17</li>
      <li>18</li><li>19</li><li>20</li><li>21</li><li>22</li><li>23</li>
      <li>24</li><li>25</li><li>26</li><li>27</li><li>28</li><li>29</li>
      <li>30</li><li>31</li><li>32</li><li>33</li><li>34</li><li>35</li>
      <li>36</li><li>37</li><li>38</li><li>39</li><li>40</li><li>41</li>
      <li>42</li><li>43</li><li>44</li><li>45</li><li>46</li><li>47</li>
      <li>48</li><li>49</li><li>50</li><li>51</li><li>52</li><li>53</li>
      <li>54</li><li>55</li><li>56</li><li>57</li><li>58</li><li>59</li>
      <li>00</li><li>01</li><li>02</li><li>03</li><li>04</li><li>05</li>
      <li>06</li><li>07</li><li>08</li><li>09</li>
    </ul>
    <ul class="digit-seconds">
      <li>20</li><li>21</li><li>22</li><li>23</li>
      <li>24</li><li>25</li><li>26</li><li>27</li><li>28</li><li>29</li>
      <li>30</li><li>31</li><li>32</li><li>33</li><li>34</li><li>35</li>
      <li>36</li><li>37</li><li>38</li><li>39</li><li>40</li><li>41</li>
      <li>42</li><li>43</li><li>44</li><li>45</li><li>46</li><li>47</li>
      <li>48</li><li>49</li><li>50</li><li>51</li><li>52</li><li>53</li>
      <li>54</li><li>55</li><li>56</li><li>57</li><li>58</li><li>59</li>
      <li>00</li><li>01</li><li>02</li><li>03</li><li>04</li><li>05</li>
      <li>06</li><li>07</li><li>08</li><li>09</li><li>10</li><li>11</li>
      <li>12</li><li>13</li><li>14</li><li>15</li><li>16</li><li>17</li>
      <li>18</li><li>19</li>
    </ul>
  </div>
  <ul class="digits">
    <li>1</li><li>2</li><li>3</li><li>4</li><li>5</li><li>6</li>
    <li>7</li><li>8</li><li>9</li><li>10</li><li>11</li><li>12</li>
  </ul>
  <div class="hours-hand"></div>
  <div class="minutes-hand"></div>
  <div class="seconds-hand"></div>
</div>

CSS3

body { font-size:62.5%; margin:1em; background:#232425 }
ul { list-style:none; margin:0; padding:0 }
#watch { font-size:1em; position:relative }
#watch .frame-face {
  position:relative;
  width:30em;
  height:30em;
  margin:2em auto;
  border-radius:15em;
  background:-webkit-linear-gradient(top, #f9f9f9,#666);
  background:-moz-linear-gradient(top, #f9f9f9,#666);
  background: linear-gradient(to bottom, #f9f9f9,#666);
  box-shadow:rgba(0,0,0,.8) .5em .5em 4em;
}
#watch .frame-face:before {
  content:'';
  width:29.4em;
  height:29.4em;
  border-radius:14.7em;
  position:absolute;
  top:.3em; left:.3em;
  background:
    -webkit-linear-gradient(135deg, rgba(246,248,249,0) 0%,rgba(229,235,238,1) 50%,rgba(205,212,217,1) 51%,rgba(245,247,249,0) 100%),
    -webkit-radial-gradient(center, ellipse cover, rgba(246,248,249,1) 0%,rgba(229,235,238,1) 65%,rgba(205,212,217,1) 66%,rgba(245,247,249,1) 100%);
  background:
    -moz-linear-gradient(135deg, rgba(246,248,249,0) 0%,rgba(229,235,238,1) 50%,rgba(205,212,217,1) 51%,rgba(245,247,249,0) 100%),
    -moz-radial-gradient(center, ellipse cover, rgba(246,248,249,1) 0%,rgba(229,235,238,1) 65%,rgba(205,212,217,1) 66%,rgba(245,247,249,1) 100%);
  background:
    linear-gradient(135deg, rgba(246,248,249,0) 0%,rgba(229,235,238,1) 50%,rgba(205,212,217,1) 51%,rgba(245,247,249,0) 100%),
    radial-gradient(ellipse at center, rgba(246,248,249,1) 0%,rgba(229,235,238,1) 65%,rgba(205,212,217,1) 66%,rgba(245,247,249,1) 100%);
}
#watch .frame-face:after {
  content:'';
  width:28em;
  height:28em;
  border-radius:14.2em;
  position:absolute;
  top:.9em; left:.9em;
  box-shadow:inset rgba(0,0,0,.2) .2em .2em 1em;
  border:.1em solid rgba(0,0,0,.2);
  background:-webkit-linear-gradient(top, #fff, #ccc);
  background:-moz-linear-gradient(top, #fff, #ccc);
  background: linear-gradient(to bottom, #fff, #ccc);
}
#watch .minute-marks li {
  display:block;
  width:.2em;
  height:.6em;
  background:#929394;
  position:absolute;
  top:50%; left:50%;
  margin:-.4em 0 0 -.1em;
}
#watch .minute-marks li:first-child {transform:rotate(6deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(2) {transform:rotate(12deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(3) {transform:rotate(18deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(4) {transform:rotate(24deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(5) {transform:rotate(36deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(6) {transform:rotate(42deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(7) {transform:rotate(48deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(8) {transform:rotate(54deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(9) {transform:rotate(66deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(10) {transform:rotate(72deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(11) {transform:rotate(78deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(12) {transform:rotate(84deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(13) {transform:rotate(96deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(14) {transform:rotate(102deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(15) {transform:rotate(108deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(16) {transform:rotate(114deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(17) {transform:rotate(126deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(18) {transform:rotate(132deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(19) {transform:rotate(138deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(20) {transform:rotate(144deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(21) {transform:rotate(156deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(22) {transform:rotate(162deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(23) {transform:rotate(168deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(24) {transform:rotate(174deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(25) {transform:rotate(186deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(26) {transform:rotate(192deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(27) {transform:rotate(198deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(28) {transform:rotate(204deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(29) {transform:rotate(216deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(30) {transform:rotate(222deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(31) {transform:rotate(228deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(32) {transform:rotate(234deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(33) {transform:rotate(246deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(34) {transform:rotate(252deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(35) {transform:rotate(258deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(36) {transform:rotate(264deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(37) {transform:rotate(276deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(38) {transform:rotate(282deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(39) {transform:rotate(288deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(40) {transform:rotate(294deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(41) {transform:rotate(306deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(42) {transform:rotate(312deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(43) {transform:rotate(318deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(44) {transform:rotate(324deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(45) {transform:rotate(336deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(46) {transform:rotate(342deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(47) {transform:rotate(348deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(48) {transform:rotate(354deg) translateY(-12.7em)}
#watch .digits {
  width:30em;
  height:30em;
  border-radius:15em;
  position:absolute;
  top:0; left:50%;
  margin-left:-15em;
}
#watch .digits li {
  font-size:1.6em;
  display:block;
  width:1.6em;
  height:1.6em;
  position:absolute;
  top:50%; left:50%;
  line-height:1.6em;
  text-align:center;
  margin:-.8em 0 0 -.8em;
  font-weight:bold;
}
#watch .digits li:nth-child(1) { transform:translate(3.9em, -6.9em) }
#watch .digits li:nth-child(2) { transform:translate(6.9em, -4em) }
#watch .digits li:nth-child(3) { transform:translate(8em, 0) }
#watch .digits li:nth-child(4) { transform:translate(6.8em, 4em) }
#watch .digits li:nth-child(5) { transform:translate(3.9em, 6.9em) }
#watch .digits li:nth-child(6) { transform:translate(0, 8em) }
#watch .digits li:nth-child(7) { transform:translate(-3.9em, 6.9em) }
#watch .digits li:nth-child(8) { transform:translate(-6.8em, 4em) }
#watch .digits li:nth-child(9) { transform:translate(-8em, 0) }
#watch .digits li:nth-child(10) { transform:translate(-6.9em, -4em) }
#watch .digits li:nth-child(11) { transform:translate(-3.9em, -6.9em) }
#watch .digits li:nth-child(12) { transform:translate(0, -8em) }
#watch .digits:before {
  content:'';
  width:1.6em;
  height:1.6em;
  border-radius:.8em;
  position:absolute;
  top:50%; left:50%;
  margin:-.8em 0 0 -.8em;
  background:#121314;
}
#watch .digits:after {
  content:'';
  width:4em;
  height:4em;
  border-radius:2.2em;
  position:absolute;
  top:50%; left:50%;
  margin:-2.1em 0 0 -2.1em;
  border:.1em solid #c6c6c6;
  background:-webkit-radial-gradient(center, ellipse cover, rgba(200,200,200,0), rgba(190,190,190,1) 90%, rgba(130,130,130,1) 100%);
  background:-moz-radial-gradient(center, ellipse cover, rgba(200,200,200,0), rgba(190,190,190,1) 90%, rgba(130,130,130,1) 100%);
  background:radial-gradient(ellipse at center, rgba(200,200,200,0), rgba(190,190,190,1) 90%, rgba(130,130,130,1) 100%);
}
@keyframes hours { to {transform:rotate(335deg)} }
#watch .hours-hand {
  width:.8em;
  height:7em;
  border-radius:0 0 .9em .9em;
  background:#232425;
  position:absolute;
  bottom:50%; left:50%;
  margin:0 0 -.8em -.4em;
  box-shadow:#232425 0 0 2px;
  transform-origin:0.4em 6.2em;
  transform:rotate(-25deg);
  animation:hours 43200s linear 0s infinite;
}
#watch .hours-hand:before {
  content:'';
  background:inherit;
  width:1.8em;
  height:.8em;
  border-radius:0 0 .8em .8em;
  box-shadow:#232425 0 0 1px;
  position:absolute;
  top:-.7em; left:-.5em;
}
#watch .hours-hand:after {
  content:'';
  width:0; height:0;
  border:.9em solid #232425;
  border-width:0 .9em 2.4em .9em;
  border-left-color:transparent;
  border-right-color:transparent;
  position:absolute;
  top:-3.1em; left:-.5em;
}
@keyframes minutes { to {transform:rotate(422deg)} }
#watch .minutes-hand {
  width:.8em;
  height:12.5em;
  border-radius:.5em;
  background:#343536;
  position:absolute;
  bottom:50%; left:50%;
  margin:0 0 -1.5em -.4em;
  box-shadow:#343536 0 0 2px;
  transform-origin:0.4em 11em;
  transform:rotate(62deg);
  animation:minutes 3600s linear 0s infinite;
}
@keyframes seconds { to {transform:rotate(480deg)} }
#watch .seconds-hand {
  width:.2em;
  height:14em;
  border-radius:.1em .1em 0 0/10em 10em 0 0;
  background:#c00;
  position:absolute;
  bottom:50%; left:50%;
  margin:0 0 -2em -.1em;
  box-shadow:rgba(0,0,0,.8) 0 0 .2em;
  transform-origin:0.1em 12em;
  transform:rotate(120deg);
  animation:seconds 60s steps(60, end) 0s infinite;
}
#watch .seconds-hand:after {
  content:'';
  width:1.4em;
  height:1.4em;
  border-radius:.7em;
  background:inherit;
  position:absolute;
  left:-.65em; bottom:1.35em;
}
#watch .seconds-hand:before {
  content:'';
  width:.8em;
  height:3em;
  border-radius:.2em .2em .4em .4em/.2em .2em 2em 2em;
  box-shadow:rgba(0,0,0,.8) 0 0 .2em;
  background:inherit;
  position:absolute;
  left:-.35em; bottom:-3em;
}
#watch .digital-wrap {
  width:9em;
  height:3em;
  border:.1em solid #222;
  border-radius:.2em;
  position:absolute;
  top:50%; left:50%;
  margin:3em 0 0 -4.5em;
  overflow:hidden;
  background:#4c4c4c;
  background:-webkit-linear-gradient(top, #4c4c4c 0%,#0f0f0f 100%);
  background:-moz-linear-gradient(top, #4c4c4c 0%, #0f0f0f 100%);
  background:-ms-linear-gradient(top, #4c4c4c 0%,#0f0f0f 100%);
  background:-o-linear-gradient(top, #4c4c4c 0%,#0f0f0f 100%);
  background:linear-gradient(to bottom, #4c4c4c 0%,#0f0f0f 100%);
}
#watch .digital-wrap ul {
  float:left;
  width:2.85em;
  height:3em;
  border-right:.1em solid #000;
  color:#ddd;
  font-family:Consolas, monaco, monospace;
}
#watch .digital-wrap ul:last-child { border:none }
#watch .digital-wrap li {
  font-size:1.5em;
  line-height:2;
  letter-spacing:2px;
  text-align:center;
  position:relative;
  left:1px;
}
#watch .digit-minutes li {
  animation:dsm 3600s steps(60, end) 0s infinite;
}
#watch .digit-seconds li {
  animation:dsm 60s steps(60, end) 0s infinite;
}
@keyframes dsm {
  to { transform:translateY(-120em) }
}

The above is the details of the clock implemented in pure CSS3. For more information about CSS3 clock, please pay attention to other related articles on 123WORDPRESS.COM!

<<:  Vue3 slot usage summary

>>:  Install Centos7 using Hyper-v virtual machine

Recommend

Introduction and tips for using the interactive visualization JS library gojs

Table of contents 1. Introduction to gojs 2. Gojs...

How to set password for mysql version 5.6 on mac

MySQL can be set when it is installed, but it see...

Alibaba Cloud Server Linux System Builds Tomcat to Deploy Web Project

I divide the whole process into four steps: Downl...

mysql implements importing only a specified table from the sql file of exported data

Scenario Yesterday the system automatically backe...

The problem of introducing specified font @font-face in CSS to be compatible with various browsers

When making a web page, if you want to use a spec...

HTML commonly used meta encyclopedia (recommended)

The Meta tag is an auxiliary tag in the head area...

How to use Font Awesome 5 in Vue development projects

Table of contents Install Dependencies Configurat...

Example of using CSS to achieve semi-transparent background and opaque text

This article introduces an example of how to use ...

Modify the maximum number of mysql connections and configuration files in docker

1. Find the mysql image docker ps 2. Enter the mi...

Example of how to identify the user using a linux Bash script

It is often necessary to run commands with sudo i...

Incredible CSS navigation bar underline following effect

The first cutter in China github.com/chokcoco Fir...

Issues with locking in MySQL

Lock classification: From the granularity of data...

Solution to the impact of empty paths on page performance

A few days ago, I saw a post shared by Yu Bo on G...

Play mp3 or flash player code on the web page

Copy code The code is as follows: <object id=&...

JavaScript to achieve progress bar effect

This article example shares the specific code of ...
