How to modify the default storage location of Docker images (solution)

Due to the initial partitioning of the system, the corresponding / partition in the operating system will not be too large, and the /var directory will not be partitioned separately. If you run the Docker service on it, after a long period of use, the originally large partition will become increasingly insufficient. How to better deal with this problem?

1. Use soft links

We know that in the operating system, by default, the storage location of the Docker container is under the /var/lib/docker directory. You can view the specific location through the following command.

#Default storage location$ sudo docker info | grep "Docker Root Dir"

The most direct and effective way to solve the problem of insufficient default storage capacity is to mount a new partition to this directory. However, in the case that the original system space remains unchanged, the soft link method is adopted to modify the storage path of the image and container to achieve the same purpose.

# Stop the Docker service $ systemctl restart docker
# Stop the Docker service $ service docker stop

Then move the entire /var/lib/docker directory to a destination path that does not take up too much space. When you start Docker at this time, you will find that the storage directory is still the /var/lib/docker directory, but it is actually stored on the data disk /data/docker.

# Move the original content $ mv /var/lib/docker /data/docker
# Link $ ln -sf /data/docker /var/lib/docker

2. Specify container startup parameters

In the configuration file, specify the container startup parameter --graph=/var/lib/docker to specify the image and container storage path. Docker's configuration file can set most of the background process parameters, and its storage location is inconsistent in each operating system. The location in Ubuntu is /etc/default/docker file and the location in CentOS is /etc/sysconfig/docker file.

# CentOS6
# Because Ubuntu enables the selinux mechanism by default OPTIONS=--graph="/data/docker" --selinux-enabled -H fd://
# CentOS7
# Modify the docker.service file and use the -g parameter to specify the storage location $ vi /usr/lib/systemd/system/docker.service
ExecStart=/usr/bin/dockerd --graph /new-path/docker
#Ubuntu
# Because Ubuntu does not enable the selinux mechanism by default OPTIONS=--graph="/data/docker" -H fd://

After restarting, the Docker path is changed to /data/docker.

# Reload the configuration file $ sudo systemctl daemon-reload
# Restart the docker service $ sudo systemctl restart docker.service

If the Docker version is 1.12 or above, you can modify or create a new daemon.json file. The modification will take effect immediately without restarting the Docker service.

# Modify the configuration file $ vim /etc/docker/daemon.json
{
    "registry-mirrors":
        ["http://7e61f7f9.m.daocloud.io"],
    "graph": "/new-path/docker"
}

3. Create a configuration file under System

Create a Drop-In file docker.conf in the /etc/systemd/system/docker.service.d directory. By default, the docker.service.d folder does not exist and must be created first. The reason for creating a Drop-In file is that we want the Docker service to use specific parameters mentioned in the docker.conf file, overwriting the parameters used by the default service in the /lib/systemd/system/docker.service file.

# Define a new storage location $ sudo vi /etc/systemd/system/docker.service.d/docker.conf
[Service]
ExecStart=/usr/bin/dockerd --graph="/data/docker" --storage-driver=devicemapper

Save and exit the vim editor. /data/docker is the new storage location, and devicemapper is the storage driver currently used by Docker. If your storage driver is different, enter the value you checked and wrote down in the first step. You can now reload the service daemon and start the Docker service, which will change the location where the new images and containers are stored. To confirm that everything went well, run the docker info command to check the Docker root directory.

# Reload the configuration file $ sudo systemctl daemon-reload
# Restart the docker service $ sudo systemctl start docker
