Docker configures the storage location of local images and containers

Use the find command to find files larger than a specified size:

 find / -type f -size +10G

Exclude a directory

find / -path "/media/xww" -type f -size +10G

How to modify the storage location of Docker local images and containers

Method 1: Soft link

By default, Docker is stored in: /var/lib/docker
You can view the specific location by running the following command:

sudo docker info | grep "Docker Root Dir"

The most direct way to solve this problem is of course to mount the partition to this directory, but my data disk has other things, which is definitely not easy to manage, so I use the method of modifying the storage path of the image and container to achieve the goal.

This method will be implemented through soft connection.

First stop the Docker service:

systemctl restart docker
Or service docker stop

Then move the entire /var/lib/docker directory to the destination path:

mv /var/lib/docker /root/data/docker
ln -s /root/data/docker /var/lib/docker

At this time, when you start Docker, you will find that the storage directory is still /var/lib/docker, but it is actually stored on the data disk. You can see the capacity changes on the data disk.

Method 2: Expandable logical volume

By default, the docker storage location is:
/var/lib/docker
Generally, we don't make the root partition too large. There are generally two solutions for storing more and more images and containers
1. Mount the large partition to /var/lib/docker:
Generally, it is chosen to create a logical partition lvm to facilitate the subsequent expansion of the group.

a. Create a new partition and format it. PS: The following operations assume that you already have an existing volume group and can directly create a logical volume. Or you can create a logical volume yourself, or use partitions directly without using logical volumes: lvcreate -L 300G lv_docker vg_home
mkfs.ext4 /dev/vg_home/lv__docker
    b. Mount the new partition to the temporary mount point [plain] view plain copy
mkdir /mnt/docker
mount /dev/vg_home/lv_docker /mnt/docker/

    c. After stopping docker, copy the data under /var/lib/docker to the temporary mount point [plain] view plain copy
service docker stop
cp -r /var/lib/docker/* /mtn/docker

    d. Modify /var/lib/docker to //var/lib/docker.bak and create /var/lib/docker
[plain] view plain copy
mv /var/lib/docker{,.bak}
mkdir /var/lib/docker

    e. Mount the new partition to /var/lib/docker and set it to mount automatically at boot.
[plain] view plain copy
mount /dev/vg_home/lv_docker /var/lib/docker
vim /etc/fstab
---
 /dev/vg_home/lv_docker /docker_data ext4 defaults 0 0
----

     f. Check whether docker is available and whether the data is complete [plain] view plain copy
docker images
docker ps -a

     g. After confirmation, uninstall the temporary mount point and delete /var/lib/docker.bak
[plain] view plain copy
umount /mnt/docker
rm -rf /var/lib/docker.bak

Method 3: Modify the storage path of images and containers

The parameter for specifying the image and container storage path is –graph=/var/lib/docker. We only need to modify the configuration file to specify the startup parameters.

The Docker configuration file can set most of the background process parameters. The storage location in each operating system is different. The location in Ubuntu is: /etc/default/docker, and the location in CentOS is: /etc/sysconfig/docker.

If it is CentOS, add the following line:

OPTIONS=--graph="/root/data/docker" --selinux-enabled -H fd://

If it is Ubuntu, add the following line (because Ubuntu does not enable selinux by default):

OPTIONS=--graph="/root/data/docker" -H fd://
# or DOCKER_OPTS="-g /root/data/docker"

Finally, restart and the Docker path will be changed to /root/data/docker.
If it does not work, do the following:

vim /etc/default/docker
Add configuration information DOCKER_OPTS="--graph=/home/docker"
Save and exit service docker restart
Found that the configuration did not take effect solution:
 mkdir -p /etc/systemd/system/docker.service.d
 cat /etc/systemd/system/docker.service.d/Using_Environment_File.conf
If the file does not exist, create it yourself and add the following content [Service]
EnvironmentFile=-/etc/default/docker
ExecStart=
ExecStart=/usr/bin/docker daemon -H fd:// $DOCKER_OPTS
Load configuration and restart service systemctl daemon-reload
service docker restart
Check whether the configuration is effective
