Rhit efficient visualization Nginx log viewing tool

Introduction

Rhit can read Nginx log files from standard folders (gzipped compressed files are also acceptable), analyze and count them, and display them in a visual table in the console without generating any unnecessary temporary files or data.

You can filter and match by date, response value, request source, etc. and perform analysis. Rhit is very efficient and can process millions of lines of log data per second.

The following are the results of searching for status codes 1xx and 2xx in the logs for January:

The project address is:

https://github.com/Canop/rhit

Install

Download and use the compiled binary file directly, but you need to make sure that the shell can find the rhit binary file. An easier way to deal with it is to put it in the /usr/local/bin directory and add executable permissions to it.

chmod +x rhit
// Download address: https://dystroy.org/rhit/download

Install from crates.io, depending on the Rust environment, use the following command to install:

cargo install rhit

Source code installation depends on the Rust environment. After cloning the GitHub source code, enter the rhit folder and run the following command:

cargo install --path .

Display Fields

rhit can automatically open the nginx log file in the default directory, or you can specify the log path in the command line parameters:

rhit my/archived/logs

Common nginx log lines are as follows:

178.133.125.122 - - [21/Jan/2021:05:49:52 +0000] "HEAD /broot/download/x86_64-pc-windows-gnu/broot.exe HTTP/1.1" 200 0 "-" "Mozilla/4.0 (compatible; MSIE 6.0; Windows NT 5.1)"

It consists of several fields: date, remote IP address, path, bytes sent, etc. rhit can execute a list of fields to sort the table. If not specified, it will be displayed by date, status code, source and path by default. If you want to specify multiple fields, separate them with commas, such as -f date,status; to display all fields, use -f all.

Date based. Use --field date, or -f date for short. By default, the length of the bar graph is based on the number of hits, but you can modify the sort key to be based on the number of bytes sent.

IP-based. By default, the remote IP is not displayed. You can use rhit -f ip to display it.

Based on the request method. The HTTP request method is not displayed by default. You can use rhit -f method to display it.

Path based. The command is rhit -f path

Based on Referer. The command is rhit -f ref

Based on status code. The command is rhit -f status

filter

Rhit provides some filters to filter the result list and display some data you want to see or don't want to see.

Filter by date. Accurate to the day, the date format is year/month/day, such as filtering data from 2021/2/15 to 2021/2/20, you can also filter data greater than a certain time, less than a certain time, or not containing a certain time (using '>', '<', '!' symbols):

Filter by remote IP. The parameter is -i, which filters a specific IP, or excludes a specific IP (using the '!' symbol).

Filter by request method. The parameter is -m, which filters specific methods or excludes specific methods.

To filter by request path, use the -p parameter, which can be exact match or regular expression (for example, all paths start with "download" and end with "exe":, the parameter is -p 'download.*exe$'):

Filter by Referer. The parameter is -r, which is consistent with the syntax for filtering by path:

Filter by status code. The parameter is -s, which filters specific status codes or excludes specific status codes.

Combined screening. The above methods can be combined in any way.

Sort Key

By default, all tables are sorted by hits, which is the sort key, and all values ​​of the sort key are shown in pink, including the histogram. If you are more interested in the number of bytes sent, you can change the sort key to bytes using -kb:
