How to install and uninstall open-vswitch in Linux

How to install and uninstall open-vswitch in Linux

1. Compile and install ovs from source code:

Install dependencies:

# apt install make
# apt install gcc
# apt install build-essential
# apt install libssl-dev
# apt install libcap-ng-dev
# apt install python2.7
# apt install python-pip
# pip install six
# apt install autoconf
# apt install automake
# apt install libtool

Download source package

# apt install git

# git clone https://github.com/openvswitch/ovs.git (the downloaded git project directory is ~/ovs)

Generate configuration files

# ./boot.sh (in the root directory of the ovs project)

Configuration

# ./configure -with-linux=/lib/modules/$(uname -r)/build

Compile

# make

# make install

# make modules_install
# config_file="/etc/depmod.d/openvswitch.conf"
# for module in datapath/linux/*.ko; do
 modname="\$(basename \${module})"
 echo "override \${modname%.ko} * extra" >> "\$config_file"
 echo "override \${modname%.ko} * weak-updates" >> "\$config_file"
 done

# depmod -a
# /sbin/modprobe openvswitch
# /sbin/lsmod | grep openvswitch

start up

export PATH=$PATH:/usr/local/share/openvswitch/scripts
# ovs-ctl start

test

# ovs-vsctl show
# ovs-vsctl add-br mybridge
# ovs-vsctl add-port mybridge eth0

2. Uninstalling Ovs

After starting ovs, if you change the ovs source code and want to update the ovs service, do the following:

# ovs-ctl stop Stop ovs service # ovs-dpctl show View the kernel, there will be a datapath of ovs-system
# ovs-dpctl del-dp ovs-system Delete the datapath that appeared in the previous step (if you do not do this step, rmmod may report an error)
# rmmod openvswitch Uninstall the openvswitch kernel module. Use lsmod | grep openvswitch to find no openvswitch.
# Enter the ovs source code directory and recompile and install according to the previous compilation steps

References

Open vSwitch on Linux, FreeBSD and NetBSD

The above is the full content of this article. I hope it will be helpful for everyone’s study. I also hope that everyone will support 123WORDPRESS.COM.
