Record the whole process of MySQL master-slave configuration based on Linux

mysql master-slave configuration

1. Preparation

Host: 192.168.244.128
Slave: 192.168.244.130

Configuring the Host

2. Authorize the slave server

GRANT REPLICATION SLAVE ON *.* to 'rep1'@'192.168.244.130' identified by 'root@bisnow';
FLUSH PRIVILEGES;

Here it means that the slave login username is configured as rep1, the password is 123, and it must be logged in from the address 192.168.248.139. After a successful login, you can operate any table in any database. If you do not need to restrict the login address, you can change the IP address to a %.

3. Modify the main library configuration file

vi /etc/my.cnf
[mysqld]
log-bin=/var/lib/mysql/binlog
server-id=130
binlog-do-db = cmdb

server-id: ID number of the master;
log-bin: Synchronized log path and file name. Be sure to note that this directory must be written by MySQL (I was lazy here and put it directly under the datadir below);
binlog-do-db: the name of the database to be synchronized

4. Restart the MySQL service after configuration is complete

systemctl restart mysqld.service

5. Check the current binary log name and offset of the master server. The purpose of this operation is to recover data from this point after starting the slave database.

mysql> show master status;

Configuring the Slave

6. Add the following configuration in /etc/my.cnf

server-id=131

Note: If the slave is copied from the master, the uuids of the two mysqls are the same and need to be modified manually. The modification location is in the auto.cnf file in the data directory.
vi /var/lib/mysql/auto.cnf

7. Use commands to configure the slave:

change master to master_host='192.168.244.128',master_port=3306,master_user='rep1',master_password='root@bisnow',master_log_file='binlog.000002',master_log_pos=120;

8. Start the slave process

9. Check the slave status. If the following two values ​​are YES, the configuration is correct:

Slave_IO_Running: Yes
Slave_SQL_Running: Yes

At this point, the configuration is complete. The host creates a library, adds data, and the slaves are automatically synchronized.
