js and jquery to achieve tab status bar switching effect

Today we will make a simple case, using js and jquery to realize the purpose of switching by clicking on the tab bar, the effect is as follows:

The code is as follows:

<!DOCTYPE html>
<html>
 <head>
  <meta charset="utf-8">
  <title>Status bar switch</title>
  <style>
   * {
    margin: 0;
    padding: 0;
    box-sizing: border-box;
   }

   .main {
    width: 720px;
    display: block;
    margin: 50px auto;
   }

   .table-title {
    width: 100%;
    height: 100%;
    border: 1px solid black;
   }

   .table-title ul {
    list-style: none;
    display: flex;
   }

   .table-title li {
    width: 25%;
    height: 100%;
    background-color: gainsboro;
    text-align: center;
    border-right: 1px solid black;
    cursor: pointer;
   }

   .table-title li:last-child {
    border-right: none;
   }

   .table-title li label {
    text-align: center;
    cursor: pointer;
   }

   .tab-box .tab-show {
    display: none;
    border: 1px solid black;
    border-top: none;
    text-align: center;
   }

   /* Display the first frame */
   .tab-box .tab-show:first-Child {
    display: block;
   }

   .change {
    opacity: 0.7;
   }
  </style>
  <script src="js/jquery-3.5.1.js"></script>
  <script>
   // js implements window.onload = function() {
    //Get elements var allLi = document.getElementsByTagName("li");
    var boxes = document.getElementsByClassName("tab-box")[0].children;
    //Traversal to achieve the switching effect for (var i = 0; i < allLi.length; i++) {
     //Define an attribute index value for each li allLi[i].index = i;
     //Add click event allLi[i].onclick = function() {
      //Get the index value var index = this.index;
      //Display content boxes[index].style.display="block";
      allLi[index].style.opacity=0.7;
      for (var j = 0; j < allLi.length; j++) {
       //Change the style of the sibling element back if(j != index){
        boxes[j].style.display="none";
        allLi[j].style.opacity=1;
       }
      }
     }
    }
   }
   // jQuery implements $().ready(function() {
    $(".table-title li").click(function() {
     //Get the element index through the .index() method, starting from 0, and assign it to a variable var _index = $(this).index();
     // Make the _indexth content box displayed and the others hidden $(".tab-box>div").eq(_index).show().siblings().hide();
     //Change the style of the option box when it is selected, and remove the styles of several other options$(this).addClass("change").siblings().removeClass("change");
    });
   });
  </script>
 </head>
 <body>
  <div class="main">
   <div class="table-title">
    <ul>
     <li><label>Mobile phone digital</label></li>
     <li><label>Computer Work</label></li>
     <li><label>Daily necessities</label></li>
     <li><label>A must-have for home</label></li>
    </ul>
   </div>
   <div class="tab-box" style="width: 100%;height: calc(100%-40px);">
    <div class="tab-show">
     Mobile phone digital
    <div class="tab-show">
     Computer Office</div>
    <div class="tab-show">
     Daily necessities
    <div class="tab-show">
     Home essentials</div>
   </div>
  </div>
 </body>
</html>

If you want to learn more, you can click on two wonderful topics: JavaScript tab operation method summary jQuery tab operation method summary

The above is the full content of this article. I hope it will be helpful for everyone’s study. I also hope that everyone will support 123WORDPRESS.COM.
