The whole process of installing and configuring Harbor1.7 on CentOS7.5

1. Download the required packages

wget -P /usr/local https://storage.googleapis.com/harbor-releases/release-1.7.0/harbor-online-installer-v1.7.1.tgz

2. Unzip the file

tar zxf /usr/local/harbor-online-installer-v1.7.1.tgz -C /usr/local/

3. Modify Harbor configuration

hostname: Configure the host name. You cannot set a host name like 127.0.0.1 or localhost. It can be an IP or domain name.

ui_url_protocol: Specifies whether to use HTTP or HTTPS protocol

Email settings: Email settings, option configuration, only effective at first startup, can be modified after logging into the UI

harbor_admin_password: Set the administrator's initial password, which is only used when logging in for the first time.

auth_mode: User authentication mode, the default is db_auth, you can also use ldap_auth authentication.

db_password: When using db, you need to specify the password to connect to the database

self_registration: whether to allow self-registration of users, the default is on, and the new version can be modified in the graphical interface.

max_job_workers: Maximum number of workers, the default is 10

customize_crt: whether to generate a certificate for token, the default is on

ssl_cert: The path to the nginx cert and key files. This is only meaningful when using the https protocol.

ssl_cert: The path to the nginx cert and key files. This is only meaningful when using the https protocol.

secretkey_path: The path of secretkey storage

admiral_url：Admiral's url, comment this attribute, or set its value to NA when Harbor is standalone

clair_db_password: The calir service is not enabled, but the following related parameter configurations should be checked in the "./prepare" file in the decompressed directory. Comments are not allowed. Otherwise, the environment preparation check will fail and "ConfigParser.NoOptionError: No option u'clair_db_password' in section: u'configuration'" related errors will be reported; or comment related checks and definitions in "./prepare", but please note that there are too many associations in the file. It is recommended to modify the "harbor.cfg" file.

ldap_url: ladp related settings. If ldap authentication is not used, the following related parameter configurations should be checked in the "./prepare" file in the decompressed directory. Comments are not allowed. Otherwise, the environment preparation check will fail and "ConfigParser.NoOptionError: No option u'ldap_timeout' in section: u'configuration'" related errors will be reported. Alternatively, comment related checks and definitions in "./prepare". However, please note that there are too many associations in the file. It is recommended to modify the "harbor.cfg" file.

ldap_scope:

self_registration: self-registration is enabled by default, off is disabled

token_expiration: token validity period, default is 30 minutes

project_creation_restriction: Create project permission control, the default is "everyone", can be set to "adminonly"

verify_remote_cert: Whether to use SSL verification when communicating with the remote registry

Other default values

4. Install docker-compose

yum install docker-compose

5. Execute prepare and install.sh in the Harbor directory

6. Other physical machines docker link to this machine

vi /etc/docker/daemon.json

join in

{
"insecure-registries" : ["Harbor warehouse address"]
}

7. Login

docker login HarborIp

Summarize
