SSM projects are frequently deployed as war packages, using tomcat and maven to implement hot deployment configuration

background

As we all know, after we develop a JavaEE project, we need to deploy the project to the server's tomcat. The common deployment method is to package the project into a war package and put it under Tomcat's webapps, then restart Tomcat, and then access it through the IP address + port number. There is no problem with this deployment itself, but the problem is that if you are still in a production environment and need to frequently change and optimize the project, you will need to frequently package the project into a war package and replace the war package under webapps, which is cumbersome.

Next, we will describe how to implement local programming and then deploy the project to the remote server's tomcat to achieve hot deployment.

Technology & Tools Used

• Maven (project building and dependency management)
• tomcat7 plugin (plugin deployed to tomcat)
• tomcat server (web server)
• The compiler recommended is IDEA

1. Ensure that the local computer has permission to use remote Tomcat

Modify the {TOMCAT_HOME}conf/tomcat-users.xml configuration file under Tomcat and add the user name, password, and permissions.

<role rolename="manager-gui" />
<role rolename="manager-script" />
<role rolename="admin-gui" />
<role rolename="admin-script" />
<user username="tomcat" password="tomcat" roles="manager-gui,manager-script,admin-gui,admin-script"/>

2. Configure Tomcat to allow remote access

Create a manager.xml file in the remote server's {TOMCAT_HOME}conf/Catalina/localhost/ directory and configure the following:

<?xml version="1.0" encoding="UTF-8"?>
<Context privileged="true" antiResourceLocking="false" docBase="${catalina.home}/webapps/manager">
     <Valve className="org.apache.catalina.valves.RemoteAddrValve" allow="^.*$" />
</Context>

Note: If you only want some users to use it, you can configure the IP in allow , for example

allow="192.168.0.102"

3. Restart remote Tomcat

Execute in the bin directory of tomcat

//Shut down tomcat
./shutdown.sh
//Start tomcat
./startup.sh

4. Test whether you have permission to use

Access tomcat, for example http://192.168.0.102:8080 (use your own server or virtual machine's IP address)
Click Manager APP

Enter the tomcat account and password just configured

If you jump to this page, the configuration is complete.

Of course, you can also deploy and replace war on the current page, which is another way of deployment, but it is still not as convenient as hot deployment.

Question: If a 403 error occurs, the following

403 Access Denied

You are not authorized to view this page.

By default the Manager is only accessible from a browser running on the same machine as Tomcat. If you wish to modify this restriction, you'll need to edit the Manager's context.xml file.

If you have already configured the Manager application to allow access and you have used your browsers back button, used a saved book-mark or similar then you may have triggered the cross-site request forgery (CSRF) protection that has been enabled for the HTML interface of the Manager application. You will need to reset this protection by returning to the main Manager page. Once you return to this page, you will be able to continue using the Manager application's HTML interface normally. If you continue to see this access denied message, check that you have the necessary permissions to access this application.

If you have not changed any configuration files, please examine the file conf/tomcat-users.xml in your installation. That file must contain the credentials to let you use this webapp.

solve

Modify the /webapps/manager/META_INF/context.xml file and comment out the restricted source settings in the file.

<Context antiResourceLocking="false" privileged="true" >
 <!--Comment here to remove the setting of access rights <Valve className="org.apache.catalina.valves.RemoteAddrValve"
     allow="127\.\d+\.\d+\.\d+|::1|0:0:0:0:0:0:0:1" />
     -->
</Context>

Then just refresh the page without restarting tomcat

5. Configure the remote Tomcat administrator account in Maven

Add the following content to the node in the local Maven {MAVEN_HOME}/conf/settings.xml file:

<!-- Configure the username and password that can operate tomcat-->
<server>
  <id>crocutax</id>
  <!-- server login name -->
  <username>tomcat</username>
  <!-- server login password -->
  <password>tomcat</password>
</server>

6. Configure Maven's tomcat7 plugin in the project

<!-- Configure Tomcat plugin-->
<plugin>
	<groupId>org.apache.tomcat.maven</groupId>
	<artifactId>tomcat7-maven-plugin</artifactId>
	<version>2.2</version>

	<configuration>
		<!-- The name here must be consistent with the id of the server node configured in {MAVEN_HOME}/conf/settings.xml-->
		<server>crocutax</server>
		<!--Server port number-->
		<port>8080</port>
		<!-- The path for project publishing is the tomcat/webapps directory by default, and you can specify a deeper directory.
		If you leave "/", the ROOT.war package will be deployed in the webapps directory by default.
		<path></path>
		<!-- Note that the URL of tomcat7 cannot be modified at will, and the suffix must be text, not html.
		 If it is a local tomcat deployment, you can use localhost or ip.
		<url>http://localhost:8080/manager/text</url>
		<!--<url>http://117.62.110.110:8080/manager/text</url>-->
		<!--Solve the problem of garbled Chinese parameters-->
		<uriEncoding>UTF-8</uriEncoding>
		<update>true</update>
		<!--Configure the user name defined in tomcat\conf\tomcat-users.xml -->
		<username>tomcat</username>
		<password>tomcat</password>
	</configuration>
</plugin>

• server : The name must be consistent with the id of the server node configured in {MAVEN_HOME}/conf/settings.xml
• port : server port number
• path : The path where the project is published. The default directory is tomcat/webapps. You can specify a deeper directory. If you leave "/", the ROOT.war package will be deployed in the webapps directory by default.
• url : Note that the url here in tomcat7 cannot be modified at will, and the suffix must be text, not html. If it is a local tomcat deployment, you can use localhost and ip. uriEncoding : Solve the problem of garbled Chinese parameters
• update : hot deployment, otherwise an error will be reported later
• Username : Configure the user name defined in {TOMCAT_HOME}\conf\tomcat-users.xml
• password : The password defined in {TOMCAT_HOME}\conf\tomcat-users.xml

7. Start Maven's tomcat deployment command in the project

For initial deployment, you can use the "tomcat7:deploy" command (used when there is no Root folder under tomcat's webapps)

If you have already deployed, use the command "tomcat7:redeploy"
If you encounter project conflicts, you can use the command
-DskipTests means skip the test

clean tomcat7:redeploy -DskipTests

When using it, an error occurs that the file cannot be found. Recompile or package it.

Use IDEA as shown below

Of course, you can also configure quick start

You can also use IDE->Terminal or the project root directory to open a DOS window and enter the Maven command

At this point, the hot deployment of tomcat+maven has been configured, and you no longer have to worry about the cumbersome packaging and deployment.
