Vue uses v-model to encapsulate the entire process of el-pagination components

Use v-model to bind the paging information object. The paging information object includes 3 core attribute parameters. The paging event is directly bound to the method of querying data, eliminating the binding event methods of handleSizeChange and handleCurrentChange of the parent component.

1. Introduction

There are already many similar articles on the Internet about developing custom paging components by encapsulating el-pagination components, but after reading them, I was always dissatisfied, so I decided to make one myself.

2. Background

2.1. Conventional paging processing method

The general practice of using the el-pagination component is as follows:

Template part:

 <el-pagination @size-change="handleSizeChange"
            @current-change="handleCurrentChange" :current-page="pageInfo.pagenum"
            :page-sizes="[5, 10, 15, 20]" :page-size="pageInfo.pagesize"
            layout="total, sizes, prev, pager, next, jumper" :total="pageInfo.total"
            background>
        </el-pagination>

Script part:

export default {
  data() {
    return {
      formData : {
        //Query information queryInfo:{
          userType : 0,
          deleteFlag: 2, // indicates all types pagenum: 1,
          pagesize : 10
        },

        // The user type selection box currently selects the displayed label value userTypeLabel: "all types",

        // The user status selection box currently displays the selected label value userStatusLabel: "all types"
      },

      // Paging information pageInfo:{
        pagenum : 1,
        pagesize : 10,
        total : 0
      }
    }
  },
  methods: {
    // Query user information list queryUsers(){
      let _this = this;
      //console.log(this.pageInfo);

      this.formData.queryInfo.pagenum = this.pageInfo.pagenum;
      this.formData.queryInfo.pagesize = this.pageInfo.pagesize;

      this.instance.queryUsers(
        this.$baseUrl,this.formData.queryInfo
      ).then(res => {
        //console.log(res.data);
        if (res.data.code == this.global.SucessRequstCode){
          //If the query is successful_this.pageInfo.total = res.data.data.length;
          _this.userInfoList = res.data.data;
        }else{
          alert(res.data.message);
        }
      }).catch(error => {
        alert('Query failed!');
        console.log(error);
      });
    },
    // Change the number of items per page handleSizeChange(newSize) {
        this.pageInfo.pagesize = newSize;
        this.queryUsers();
    },
    // The current page number changes handleCurrentChange(newPage) {
        this.pageInfo.pagenum = newPage;
        this.queryUsers();
    }
  }

2.2 Problem Analysis

Each paging query requires a set of similar methods, which are somewhat simple and repetitive, but also slightly different, that is, the method of querying data will be different.

For programmers with obsessive-compulsive disorder, simple and repetitive code is undoubtedly very unpleasant. Therefore, it needs to be componentized.

Analysis of el-pagination paging components:

There are three core attribute parameters: current page number (current-page), number of records per page (page-size), and total number of records (total). The core attribute parameters implement bidirectional linkage by binding the parent component page data. The current page number and the number of records per page are generally changed by operating the paging subcomponent, and the total number of records is set by the parent component after querying the data.
There are two events: @size-change (number of items per page changed event) and @current-change (current page number changed event). These two events are bound to the corresponding event processing methods handleSizeChange and handleCurrentChange of the parent component respectively. Both of them call the data query method. In the data query method, after obtaining the result set, the total number of records is set.

The development goal of the custom paging component is to eliminate the binding event methods of handleSizeChange and handleCurrentChange of the parent component.

Idea: Use v-model to bind the paging information object. The paging information object includes 3 core attribute parameters, namely the pageInfo mentioned above. Then the paging event is directly bound to the method of querying data.

3. Implementation of the plan

3.1. Custom paging components

Write a custom pagination component code, the file is /src/Pagination.vue. The code is as follows:

<template lang="html">
  <div class="pagination">
    <el-pagination
      @size-change="handleSizeChange"
      @current-change="handleCurrentChange"
      :current-page.sync="pageInfo.pagenum"
      :page-size="pageInfo.pagesize"
      :page-sizes="pageSizes"
      :total="pageInfo.total"
      layout="total, sizes, prev, pager, next, jumper"
      background >
    </el-pagination>
  </div>
</template>

<script>
  export default {
    name : "pagination",
    model : {
        prop : 'pageInfo',
        event : 'change'
    },
    props : {
      //Select the number of items per page pageSizes: {
        type: Array,
        default() {
          return [5, 10, 15, 20];
        }
      },
      // data object pageInfo bound to v-model: {
        type: Object,
        reuqired:true
      }
    },
    data(){
      return {
      }
    },
    methods: {
      handleSizeChange(newSize) {
        var newValue={
					pagesize : newSize,
					pagenum : newSize <= this.total ? 1 : this.pageInfo['pagenum']
				};
        this.$emit('change',Object.assign(this.pageInfo,newValue));
        this.$emit('pagination');
      },
      handleCurrentChange(newPage) {
        this.$emit('change',Object.assign(this.pageInfo,{pagenum : newPage}));
        this.$emit('pagination');
      }
    }
  }
</script>

<style lang="css" scoped>
.pagination {
    padding: 10px 0;
    text-align: center;
}
</style>

A custom paging component named pagination, which uses v-model to achieve two-way data communication. When the page number or the number of items per page changes, the pagination event @pagination is triggered, providing binding with the parent component method.

The field structure of pageInfo is stipulated as follows:

  pageInfo:{
        pagenum : 1, //Number
        pagesize : 10, //Number
        total : 0 //Number
      }

The parent component must provide a data object of the same structure to bind the pageInfo object inside the component.

3.2. Register the paging component

Then register this paging component and add the following code in main.js:

import pagination from '@/components/Pagination.vue'

//Register paging plugin Vue.component('pagination', pagination)

3.3. Parent component calling method

Modify the code in the previous Chapter 2 using the pagination component.

Template part:

  <!-- Paging area -->
        <pagination v-model="pageInfo" @pagination="queryUsers"></pagination>

Script part:

export default {
  data() {
    return {
      formData : {
        //Query information queryInfo:{
          userType : 0,
          deleteFlag: 2, // indicates all types pagenum: 1,
          pagesize : 10
        },

        // The user type selection box currently selects the displayed label value userTypeLabel: "all types",

        // The user status selection box currently displays the selected label value userStatusLabel: "all types"
      },

      // Paging information pageInfo:{
        pagenum : 1,
        pagesize : 10,
        total : 0
      }
    }
  },
  methods: {
    // Query user information list queryUsers(){
      let _this = this;
      //console.log(this.pageInfo);

      this.formData.queryInfo.pagenum = this.pageInfo.pagenum;
      this.formData.queryInfo.pagesize = this.pageInfo.pagesize;

      this.instance.queryUsers(
        this.$baseUrl,this.formData.queryInfo
      ).then(res => {
        //console.log(res.data);
        if (res.data.code == this.global.SucessRequstCode){
          //If the query is successful_this.pageInfo.total = res.data.data.length;
          _this.userInfoList = res.data.data;
        }else{
          alert(res.data.message);
        }
      }).catch(error => {
        alert('Query failed!');
        console.log(error);
      });
    }
  }

In this way, the handleSizeChange and handleCurrentChange event response methods are removed. When the paging information changes, the bound queryUsers method is triggered.

In addition, if you need to adjust pageSizes, set it in the template as follows:

:pageSizes=[10,20,30,50,100]

4. References

The development of this component mainly refers to the following articles:

Vue+el-pagination secondary encapsulation, https://blog.csdn.net/weixin_47259997/article/details/107887823.

The vue project uses el-pagination in elementui to encapsulate the common paging component, https://www.jianshu.com/p/e241e5710fb0/.

This concludes this article about the entire process of Vue using v-model to encapsulate el-pagination components. For more relevant v-model encapsulation el-pagination component content, please search 123WORDPRESS.COM's previous articles or continue to browse the following related articles. I hope everyone will support 123WORDPRESS.COM in the future!
